优质HDMI.USB3.0电线对绞机

机器特点： Technical features ■用途广:适用于高频线、数据线、电子线芯线对绞及多股绞合Used abroad: It is used in high frequnce cable, data cable,electical core wire and many kinds of group twisting . ■产能高:高转速，生产效率是立式的2倍High output: High speed of rotation ,the production efficiency more than vertical 2 times . ■张力稳:包带及收线张力从空盘到满盘保持恒张力Tension is steady : Wrapping and take up tension keep constant from start to end. ■绞距准:机械绞距，加减速及正常工作时绞距恒定Lay ccurate :Machinery lay , when acceleration and deceleration, and the normal woork ,the lay can be keep constant ■扁平电缆好:收线排位采用轴排式结构，排幅排距任意设定Good traversing:Take-up arrangement ■品质高:制作HDMI，DP等高频线材，合格率100% High quality:Product the HDMI DP and so on ,rate of pass100% 机器型号 ST500卧式高速旋臂单绞机 Type ST500Horizontal high speed contilever single twister 机器用途 HDMI、DP、USB、CAT-7等高频线、数据线、电子线芯线对绞及多股绞合 Purpose HDMI、DP、USB、CAT-7 and so on high speed of rotation ,the production efficiency is vertical 2 times 芯线规格Core specification AWG32~AWG20 绞距范围pitch 15~60mm 机器转速Max rpm MAX1000rpm 机器动力Power 主机:5HP / 放线:1/2HP Main engine:5HP / Pay- off :1/2HP 芯线张力 直线滑轨+滑块重锤式 / 机械扛杆+滑块移动式 , 配在线张力检测显示 Core tension Linear Guidways+Slide weight hommer type/ Mechanical lever+Slide moveing,with the tension test 包带张力 恒张力电磁刹车轮 / 自动张力追踪仪 , 包带张力从满盘到空盘保持恒定,不须人工调整 Taping tension Constant tension electromagnetism brake wheel/Automatic tension trace instrument,taping tension keep constant from start to end. 收线张力 电磁张力,自动追踪,收线张力从满盘到空盘保持恒定,不须人工调整 Take-up tension Electricle tension,by itself ,take-up tension keep constant from start to end. 扁平电缆方式 Traversing style 轴排式收线,线材排位过程中无推/拉力损伤,排幅排距根据线材规格任意设定
